ROTO 35 FS UAV Engine EFI 1300W

CAD$0.00 CAD$0.00
SKU #:
03-00011300UAV
Special Order
ROTO 35 FS UAV Engine EFI 1300W is available to buy in increments of 1

Introducing a single-cylinder four-stroke engine, air-cooled, controlled by a CDI unit with a preset advance curve for smooth operation, designed for use in UAV projects. It is most sought after for V-TOL projects, where this engine is commonly used due to its acceptable weight, good performance, and especially low fuel consumption.

Special Order

TECHNICAL SPECIFICATION

TBO ; 200 / 100 Hours

Displacement ; 34,3 ccm

Power ; 2,3 kW

Fuel consuption ; 360g/h

Ignition Electronic ; 4-14V

Cooling ; Air Cooled

Lubrication ; Petrol 95 oct. + 2% oil

Speed ; 1200 - 6500 rpm

Engine weight ; 1740g

Ignition weight ; 160g

Special Order
More Information
Features

Start generator

Start generators under the trademark „STG Roto“ 1000W and 2000W.
All types are designed for maximum performance and efficiency. STG Roto start generators cooperate exclusively with the E-Control control unit, electronic system designed to control the engine generator, which allows the remote start of the internal combustion engine, charging batteries and hybrid operation, increasing the power of the internal combustion engine (Hybrid system).

start generator for uav engine

+ Remote start & stop

+ Hybrid system

+ Hybrid boost

generator for uav engine


Generator

Generators under the trademark „AL Roto“ in range 300 up to 2000W.
Power generator has been developed with Roto regulators that can provide a stabilized voltage of 3.3V-60V. These generators do not have the ability to remotely start the internal combustion engine. Their advantage is that they provide high power in a stabilized voltage energy suitable for direct power consumption on board your project.

+ Low purchase price

+ Stabilized voltage energ

Electronic Fuel Injection

The big advantage of Electronic Fuel Injection is the possibility to achieve very low fuel consumption. EFI installed on a Roto 125 FS engine achieves fuel savings of up to 40% compared to a carbureted engine.

The economic cost of an EFI Roto is higher than a carbureted engine, but if your project reaches series production the purchase price of the EFI will drop significantly due to the use of EFI LIGHT / Production. With the production version it is assumed that equipment such as Lambda probes, temperature sensors and adjustment modules will no longer be required for the EFI setup. At the time of series production, the economic costs will be offset by the lower price of EFI Light and the low fuel consumption. Another major advantage is the flight levels above 5000 meters above sea level.

Electronic Fuel Injection for uav engine

+ low fuel consumption

+ Electronic control

+ flight level 5000 m.a.s.l.

Fuel consumption uav engine


Carburetor

Carburetor is a very good and inexpensive option for projects flying at flight levels below 2000 meters above sea level.

For missions lasting up to 5 hours, the carburetor is a good choice for both project cost and fuel economy.The carburetor can be set up directly for your project, where we at Roto Motor Ltd will preset the PWM values for your mission and determine the best conditions for your engineers to control the throttle of the carburetor, in PWM values.By maintaining basic parameters such as CHT and EGT temperatures, you can count on reliable and inexpensive operation of ROTO four-stroke engines.

+ Low purchase price

+ Simple control

Manufacturer Roto Motor
