ROTO 170 FS UAV Engine EFI 550W
Introducing a four-cylinder, four-stroke engine, air-cooled, is equipped with a controlled CDI unit with a preset advance curve for smooth operation. This engine stands out for its very smooth operation without vibrations. These low vibrations are achieved by the engine's design, where as an opposed boxer it has excellent characteristics in all projects where it is necessary to ensure smooth operation without vibrations. Its excellent fuel consumption is also achieved by the option to use Roto EFI equipment for reaching high altitudes or low fuel consumption. The Roto 170 FS UAV has a high lifespan, thanks to the materials used in pistons and cylinder liners.
TECHNICAL SPECIFICATION
TBO ; 200 / 100 Hours
Displacement ; 162ccm
Power ; 9,8 kW
Fuel consuption ; 1 553g/h
Ignition Electronic ; 4-14V
Cooling ; Air Cooled
Lubrication ; Petrol 95 oct. + 2% oil
Speed ; 1200 - 6500 rpm
Engine weight ; 5050g
Ignition weight ; 370g
Features | Start generatorStart generators under the trademark „STG Roto“ 1000W and 2000W. ![]() + Remote start & stop + Hybrid system + Hybrid boost ![]() GeneratorGenerators under the trademark „AL Roto“ in range 300 up to 2000W. + Low purchase price + Stabilized voltage energ Electronic Fuel InjectionThe big advantage of Electronic Fuel Injection is the possibility to achieve very low fuel consumption. EFI installed on a Roto 125 FS engine achieves fuel savings of up to 40% compared to a carbureted engine. The economic cost of an EFI Roto is higher than a carbureted engine, but if your project reaches series production the purchase price of the EFI will drop significantly due to the use of EFI LIGHT / Production. With the production version it is assumed that equipment such as Lambda probes, temperature sensors and adjustment modules will no longer be required for the EFI setup. At the time of series production, the economic costs will be offset by the lower price of EFI Light and the low fuel consumption. Another major advantage is the flight levels above 5000 meters above sea level. ![]() + low fuel consumption + Electronic control + flight level 5000 m.a.s.l. ![]() CarburetorCarburetor is a very good and inexpensive option for projects flying at flight levels below 2000 meters above sea level. For missions lasting up to 5 hours, the carburetor is a good choice for both project cost and fuel economy.The carburetor can be set up directly for your project, where we at Roto Motor Ltd will preset the PWM values for your mission and determine the best conditions for your engineers to control the throttle of the carburetor, in PWM values.By maintaining basic parameters such as CHT and EGT temperatures, you can count on reliable and inexpensive operation of ROTO four-stroke engines. + Low purchase price + Simple control |
---|---|
Manufacturer | Roto Motor |
